Morris Products 91654 Lay-In Ground Clamp 1/2 inches - 1 inches

Product Description

The Morris Products 91654 Lay-In Ground Clamp is designed to accommodate large AWG ground wires with ease. This heavy-duty clamp connects ground conductors to water pipes, ground rods, copper tubing, or rebar up to 1 inch in diameter. It is suitable for direct burial in earth and concrete, providing a secure connection for #8 through 4/0 ground conductors. The lay-in feature allows for fast and easy insertion of ground electrodes.

• UL467 Listed for direct burial and grounding bonding applications, cULus certified.
• Accommodates #8 through 4/0 AWG ground conductors.
• Constructed from high-strength, high-conductivity copper with stainless steel set screws.

Product Highlights

Features a lay-in design for easy insertion of ground electrodes and is suitable for direct burial in earth and concrete.

Product Information

Standard Information

• Brand: MORRIS PRODUCTS
• Manufacturer Part Number: 91654

Technical Specifications

• Clamp Size: 1/2" - 1"
• Certification: UL467 Listed, cULus
• Direct Burial: Yes
• Material: High Strength High Conductivity Copper
• Ground Conductor Range: #8 Through 4/0 AWG
• Set Screw Material: Stainless Steel
