Morris 97308 Clear Insulated Connector In-Line 2 Ports 600-250

Product Description

The Morris Products 97308 Clear Insulated Connector is built for wiring connections within the range of 600-250. Designed as an in-line connector with two ports, this product allows for visual confirmation of conductor placement due to its clear insulation. The connector is made from 6061-T6 aluminum, making it suitable for both copper and aluminum wiring. It comes pre-filled with an oxide inhibitor for enhanced connection reliability.

• Clear insulation enables easy visual inspection of conductor insertion.
• In-Line design with dual rating for copper and aluminum wire.
• Single piece molded insulation offers durability and resistance to chemicals and abrasion.

Product Highlights

Ideal for electricians and technicians, this component is designed for reliable and safe electrical connections.

Product Information

Standard Information

• Brand: Morris
• Part Number: 97308

Technical Specifications

• Connector Type: In-line
• Insulation Material: Plastisol
• Material: Aluminum, Copper
• Temperature Rating: -49°F to 194°F
• Material Type: 6061-T6 Aluminum
• Electrical Supplies Type: Insulated Connectors
• Maximum Voltage: 600
• Wire Range: 600-250
• Number of Ports: 2
• UL Listed: Yes
• Standard: ANSI C119.4|cULus 486b Listed
