Moroso 90812 Aluminum Mechanical Lug 1/0-2 Awg

Product Description

The MOROSO 90812 is an aluminum mechanical lug designed for terminating and connecting aluminum conductors in electrical distribution and grounding applications. Rated for use with 1/0 to 2 AWG conductors, this lug provides a secure, code-compatible mechanical connection without the need for soldering or crimping tools. Aluminum mechanical lugs are a standard component in panelboards, load centers, and service entrance equipment where aluminum wiring is specified. Installation is performed by licensed electricians working to NEC requirements.

This lug is suited for use in residential and light commercial electrical installations where aluminum conductors are routed to panelboards, disconnect switches, or bussed distribution equipment. The 1/0 to 2 AWG conductor range covers common aluminum service and feeder wire sizes used in single-phase and three-phase service entrance configurations. It is an appropriate field replacement or new-installation component when working with aluminum wiring systems.

Key Features

• Accepts 1/0 to 2 AWG aluminum conductors
• Mechanical lug design — no crimp tool required for termination
• Aluminum construction suited for use with aluminum conductors
• Compatible with standard panelboard and disconnect lug mounting arrangements

Compatibility

Designed as an OEM-style mechanical lug replacement or new-installation component for electrical panels, load centers, and disconnect enclosures accepting 1/0 to 2 AWG aluminum conductors.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the panel or disconnect before handling any lug connections. Aluminum conductors must be prepared with an appropriate antioxidant compound before termination, per NEC guidelines for aluminum wiring. Do not use this lug with copper conductors unless the lug is explicitly rated AL-CU.

Technical Specifications

• Conductor Range: 1/0 to 2 AWG
• Material: Aluminum
• Connection Type: Mechanical lug
• UPC: 60198690812

Standard Information

• Brand: MOROSO
• Manufacturer Part Number: 90812
