Molex 130154-0048 Watertite Extreme Standard Molded Y Cordset

Product Description

The Molex 130154-0048 Watertite Extreme Standard Molded Y Cordset is designed for reliable electrical connections in tough environments. This is a 2-pole/3-wire cordset with a NEMA 5-15 configuration and a duplex receptacle type. It features a male-female gender and is built with a F2 1/2 cord grip body size. The cordset contains a 12/3 SOOW cord type and operates at a maximum current of fifteen amps and at one hundred twenty-five volts. It has been specifically engineered to withstand moisture and insects from high-pressure washdowns.

• IP67 rated for dust and water protection
• Measures 0.91 meters or three feet in length
• Ideal for standard male/female connections

Product Highlights

This cordset is built to resist environmental challenges making it suitable for demanding applications.

Product Information

Standard Information

• Status: Active
• Category: Wiring Devices

Technical Specifications

• Series: 130154
• IP Rating: IP67
• NEMA Configuration: NEMA 5-15
• Type: Molded Y Cordset
• Maximum Current per Contact: 15.0A
• Maximum Voltage: 125V
• Cord Grip Body Size: F2 1/2
• Cord Type: 12/3 SOOW
• Gender: Male-Female
• Cord Length: 0.91m (3.0')
• Material: Rubber
• Temperature Rating: -40 to 75 degrees C
• Application: Suitable for various electrical applications
• Conductor Size: 12 AWG
• Color: Yellow
• Electrical Rating: 15 A 125 VAC
