Mitutoyo 551-341-20 Electronic Caliper 0-12 in IP67

Product Description

The MITUTOYO 551-341-20 is a 12-inch ABSOLUTE Digimatic electronic caliper designed for precision dimensional measurement in demanding shop and field environments. It delivers 0.0005-inch resolution and 0.0020-inch accuracy across a full 0 to 12-inch (0 to 300 mm) range. The caliper body and jaws are machined from stainless steel, and the IP67 rating means it withstands coolant splash, cutting fluid exposure, and wash-down conditions without damage to the encoder or display. A built-in data output port allows direct transmission of measurements to a SPC data collector or PC, eliminating manual transcription errors. Licensed metrology technicians, machinists, and quality inspectors are the primary users.

This caliper is suited for inside diameter and outside diameter measurements in manufacturing, quality control, and toolroom applications. The nib-style and knife-edge jaw configuration allows both standard OD and ID gripping as well as reach into slots and grooves. The minimum inside diameter measurement is 0.4000 inches (10 mm), and the maximum inside diameter capacity matches the full 12-inch range. A sliding jaw adjustment and included holster round out the package for daily production use. The unit ships with a silver oxide SR44 battery installed and is TUV Rheinland certified for measurement integrity.

Key Features

• IP67-rated for full protection against coolant, cutting fluid, and wash-down exposure
• 0.0005-inch resolution with 0.0020-inch accuracy over the full 0 to 12-inch range
• Stainless steel body and stainless steel jaws for corrosion resistance and long service life
• Nib and knife-edge jaw styles support OD, ID, and slot measurements
• Data output port for direct SPC integration and error-free measurement logging
• TUV Rheinland certified; ships with SR44 silver oxide battery and holster included

Compatibility

The 551-341-20 is part of the MITUTOYO 551 ABSOLUTE Digimatic series and is compatible with MITUTOYO SPC data output accessories and compatible data collectors that accept standard Digimatic serial output.

Installation Notes

No installation is required for handheld calipers; however, technicians should verify zero calibration at the closed jaw position before taking measurements. Keep the measuring faces clean and free of chips or burrs before use. When connecting to SPC data collection equipment, use only manufacturer-compatible cables and interface units to avoid signal errors. Store in the included holster when not in use to protect the jaws and encoder strip.
