Mitutoyo 505-734 Dial Caliper 150mm 0.02mm Graduation

Product Description

The MITUTOYO 505-734 is a dial caliper designed for precise dimensional measurement in shop, field, and inspection environments. It covers a measurement range of 150 mm with a dial graduation of 0.02 mm and 2 mm per revolution, delivering an accuracy of 0.03 mm. The body and beam are constructed from stainless steel with a titanium nitride coating for corrosion and wear resistance. The jaws are carbide tipped for extended service life. A yellow dial face on a black dial case provides clear, fast readability in variable lighting conditions. Machinists, quality technicians, HVAC fabricators, and plumbing tradespeople use this tool for outside, inside, depth, and step measurements.

This caliper is suited for residential and commercial trade applications requiring repeatable, direct-reading measurement without electronic components. It performs outside, inside, depth, and step measurements in a single instrument. The 40 mm jaw length accommodates a range of workpiece geometries. The sliding jaw adjustment type allows smooth, controlled positioning. The instrument ships in a fitted plastic case for storage and transport protection. It is appropriate for use in fabrication shops, on service vehicles, and at job sites where a reliable analog measurement tool is required.

Key Features

• 150 mm measurement range with 0.02 mm dial graduation for precise readings
• Accuracy of 0.03 mm, meets proprietary inspection certification standard
• Stainless steel body with titanium nitride coating for corrosion and wear resistance
• Carbide tipped jaws for extended durability in repeated use
• Yellow dial face on black case for high-contrast, fast readability
• Measures outside, inside, depth, and step dimensions in one tool
• Supplied in a fitted plastic case for protection and organized storage

Compatibility

Designed as a general-purpose dial caliper for dimensional measurement tasks across machining, fabrication, HVAC duct work, plumbing, and quality inspection applications where a 150 mm analog caliper is required.

Installation Notes

No installation is required for this hand tool. Before use, verify the jaws are clean and the dial reads zero with the jaws fully closed, adjusting the bezel to zero if needed. Avoid dropping or overtightening the jaw against the workpiece, as this can affect calibration. Store in the supplied fitted plastic case when not in use to protect the graduated beam and dial mechanism.
