Mitutoyo 182-163 Steel Rule 24 Inch 5R Rigid

Product Description

The MITUTOYO 182-163 is a rigid stainless steel rule measuring 24 inches in overall length and 1-3/16 inches in overall width. Finished with a satin chrome plating in silver, it provides a low-glare reading surface suited to workshop and field use. The rule carries three graduation scales: 1/100 inch, 1/32 inch, and 1/64 inch, arranged in a 5R graduation style for versatile layout and measurement tasks. At 0.05 inches thick, it holds its shape under normal bench and layout work without flexing. It is a standard hand tool used by machinists, pipefitters, fabricators, and trade technicians who require accurate linear measurement.

This rule is appropriate for general-purpose layout, inspection, and measurement in residential, commercial, and industrial settings. It suits precision sheet metal layout, pipe fitting measurement, and any application where multiple fractional and decimal inch scales are needed on a single rule. The horizontal scale orientation and rigid construction make it practical for direct contact measurement against a workpiece or as a reference edge during marking. It is sold individually and requires no additional accessories for standard use.

Key Features

• 24-inch overall length with 1-3/16-inch width for wide, stable readings
• 5R graduation style with 1/100, 1/32, and 1/64 inch scales on a single rule
• Rigid stainless steel construction resists bending and corrosion
• Satin chrome finish reduces glare for improved readability
• 0.05-inch thickness provides consistent flatness across the full length
• No hook, non-magnetic — suited for use near sensitive equipment

Compatibility

Designed as a general-purpose rigid stainless steel rule suitable for standard layout and measurement applications across the mechanical, plumbing, and fabrication trades.

Installation Notes

No installation is required for this hand measurement tool. Keep the rule clean and dry to preserve the satin chrome finish and graduation legibility. Avoid using the rule as a cutting guide with rotary tools, as edge damage will compromise measurement accuracy. Store flat or in a protective sleeve to prevent warping or surface scratching.
