Mitutoyo 176-135 Microscope Reticle Concentric Circle

Product Description

The MITUTOYO 176-135 is a concentric circle reticle designed for use with Mitutoyo Series 176 Toolmaker's Microscopes. A reticle is an optical insert placed in the eyepiece or image plane of a microscope to provide a reference pattern for measurement and alignment tasks. The concentric circle pattern allows technicians and quality control professionals to precisely center, align, and measure circular features on workpieces. This reticle does not include a magnifying lens and is sold as a single unit replacement or spare component.

This reticle is intended for precision measurement environments such as tool and die shops, metrology labs, and quality inspection stations. It fits within the Mitutoyo Series 176 Toolmaker's Microscope system, which is commonly used for measuring small parts, scribing layouts, and inspecting machined features. Installation and use are suited to metrology technicians, machinists, and quality engineers working with optical measurement equipment.

Key Features

• Concentric circle reticle pattern for centering and circular feature measurement
• Designed specifically for Mitutoyo Series 176 Toolmaker's Microscopes
• Does not include a magnifying lens — reticle component only
• Sold as a single unit per package

Compatibility

Designed for use with Mitutoyo Series 176 Toolmaker's Microscopes as stated by the manufacturer.

Installation Notes

Reticle installation should be performed by a qualified metrology technician or optical instrument professional. Power down or disconnect any illumination source on the microscope before handling eyepiece components. Handle the reticle by its edges only to avoid contaminating the optical surface. Consult the Series 176 instrument manual for proper seating and orientation procedures specific to the eyepiece assembly.
