Mitsubishi Multi-Zone 40500 BTU R-454B 20 SEER2 4-Zone Wall-Mounted Mini Split Heat Pump System - 6K+6K+15K+24K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-5D42NL outdoor condenser and three wall-mounted air handlers (MSZ-GX06NL, MSZ-GX15NL, and MSZ-GX24NL), providing a complete solution for efficient multi-zone heating and cooling. The outdoor unit supports up to five indoor zones, making it ideal for both residential and light commercial applications. Each air handler is designed with advanced features such as built-in Wi-Fi, energy-efficient operation, and superior filtration systems, ensuring optimal comfort and air quality throughout your space.

What's Included

• MITSUBISHI ELECTRIC MXZ-5D42NL - 42k BTU M-Series Outdoor Condenser (Qty x1)
• MITSUBISHI ELECTRIC MSZ-GX06NL - R454B 6k BTU Heat Pump Wall Mount Air Handler (Qty x2)
• MITSUBISHI ELECTRIC MSZ-GX15NL - R454B 15k BTU Heat Pump Wall Mount Air Handler (Qty x1)
• MITSUBISHI ELECTRIC MSZ-GX24NL - R454B 24k BTU Heat Pump Wall Mount Air Handler (Qty x1)

Key Details

• Weight of Bundle: 288 lb (Mitsubishi 194 lb + Mitsubishi 44 lb + Mitsubishi 22 lb + Mitsubishi 28 lb)
• Cooling Capacity: 42,000 BTU (MXZ-5D42NL), 6,000 BTU (MSZ-GX06NL), 15,000 BTU (MSZ-GX15NL), 24,000 BTU (MSZ-GX24NL)
• Heating Capacity: 53,600 BTU (MXZ-5D42NL), 7,200 BTU (MSZ-GX06NL), 18,000 BTU (MSZ-GX15NL), 27,600 BTU (MSZ-GX24NL)
• SEER2: Up to 28.4 (MSZ-GX models)
• Refrigerant: R-454B
• Voltage: 208/230V
• Indoor Unit Dimensions: Vary by model (Height: 11.37 to 12.81 in, Width: 31.40 to 43.31 in, Depth: 9.65 to 10.13 in)
• Noise Level: As low as 19 dB(A) (MSZ-GX models)

Use & Compatibility

This bundle is ideal for multi-zone heating and cooling, suitable for residential and light commercial spaces. The outdoor condenser connects seamlessly with the included wall-mounted air handlers, which can be used in both single and multi-zone configurations. With built-in Wi-Fi and advanced filtration, these units ensure efficient climate control and improved air quality.
