Mitsubishi Multi-Zone 40500 BTU R-454B 16 SEER2 3-Zone Ducted Low-Static Mini Split Heat Pump System - 12K+15K+15K

Description

This comprehensive bundle features the Mitsubishi Electric MXZ-5D42NL outdoor condenser and two concealed duct air handling units (AHUs) - the SEZ-AD12NL and SEZ-AD15NL. The MXZ-5D42NL is designed for multi-zone heating and cooling, capable of connecting up to five indoor units, making it perfect for both residential and light commercial applications. The SEZ-AD12NL and SEZ-AD15NL units provide efficient climate control while remaining discreetly hidden within ductwork. Together, these components create a powerful and efficient HVAC system that ensures optimal comfort across multiple zones.

What's Included

• MITSUBISHI ELECTRIC MXZ-5D42NL - Mitsubishi Electric MXZ-5D42NL 42k BTU (3.5 Ton) M-Series Outdoor Condenser up to 5 Zones (Qty x1)
• MITSUBISHI ELECTRIC SEZ-AD12NL - Mitsubishi Electric SEZ-AD12NL 12k BTU (1.00 Ton) 208/230V M-Series Concealed Duct AHU (R-454B) (Qty x1)
• MITSUBISHI ELECTRIC SEZ-AD15NL - Mitsubishi Electric SEZ-AD15NL 15k BTU (1.25 Ton) 208/230V M-Series Concealed Duct AHU (R-454B) (Qty x2)

Key Details

• Weight of Bundle: 341 lb (Mitsubishi 194 lb + Mitsubishi 49 lb + Mitsubishi 98 lb)
• Cooling Capacity: 42,000 BTU (MXZ-5D42NL), 12,000 BTU (SEZ-AD12NL), 15,000 BTU (SEZ-AD15NL)
• Heating Capacity: 53,600 BTU (MXZ-5D42NL), 13,600 BTU (SEZ-AD12NL), 15,000 BTU (SEZ-AD15NL)
• SEER2 Rating: 19.3 (MXZ-5D42NL)
• Refrigerant Type: R-454B
• Voltage: 208/230V
• Sound Level: 23-59 dB(A)
• Dimensions: MXZ-5D42NL (31.43" H x 37.45" W x 13" D), SEZ-AD12NL (7.875" H x 39" W x 27.5625" D), SEZ-AD15NL (7.875" H x 39" W x 27.5625" D)
• Multi-Zone Compatibility: Yes (MXZ-5D42NL)

Use & Compatibility

This bundle is designed for efficient heating and cooling in residential and light commercial spaces. The MXZ-5D42NL outdoor condenser is compatible with multiple indoor units, while the SEZ-AD12NL and SEZ-AD15NL AHUs can be integrated into single or multi-zone systems. Ideal for applications requiring discreet climate control, these units ensure optimal comfort and energy efficiency.
