Mitsubishi Multi-Zone 28600 BTU R-454B 20 SEER2 4-Zone Wall-Mounted Hyper Heat Mini Split Heat Pump System - 6K+6K+6K+18K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-4D30NL outdoor condenser and two Mitsubishi Electric wall-mounted air handlers (MSZ-FX06NL and MSZ-FX18NL), providing a versatile and efficient heating and cooling solution for residential or light commercial spaces. The outdoor unit supports up to four zones, making it ideal for multi-zone applications. Each wall-mounted unit offers advanced features such as quiet operation, built-in Wi-Fi, and superior filtration systems, ensuring optimal comfort and air quality throughout your property.

What's Included

• MITSUBISHI ELECTRIC MXZ-4D30NL - Mitsubishi Electric MXZ-4D30NL 30k BTU (2.5 Ton) M-Series Outdoor Condenser (Qty x1)
• MITSUBISHI ELECTRIC MSZ-FX06NL - Mitsubishi Electric MSZ-FX06NL FX-Series Wall Mounted Unit 6k BTU Hyper Heat Air Handler (Qty x3)
• MITSUBISHI ELECTRIC MSZ-FX18NL - Mitsubishi Electric MSZ-FX18NL FX-Series Wall Mounted Unit 18k BTU Hyper Heat Air Handler (Qty x1)

Key Details

• Weight of Bundle: 254.4 lb (Mitsubishi 131 lb + Mitsubishi 87 lb + Mitsubishi 36.4 lb)
• Cooling BTU: 30000 (MXZ-4D30NL), 6000 (MSZ-FX06NL), 18000 (MSZ-FX18NL)
• Heating BTU: 36000 (MXZ-4D30NL), 9000 (MSZ-FX06NL), 17000 (MSZ-FX18NL)
• SEER Rating: 21 (MXZ-4D30NL), Up to 35 (MSZ-FX06NL), 25.5 (MSZ-FX18NL)
• Voltage: 208/230V (All Units)
• Dimensions: MXZ-4D30NL - 31.43" H x 37.45" W x 13" D; MSZ-FX06NL & MSZ-FX18NL - 12" H x 39.27" W x 9.75" D
• Weight: MXZ-4D30NL - 137 lbs; MSZ-FX06NL & MSZ-FX18NL - 36.4 lbs each
• Refrigerant Type: R454B (All Units)

Use & Compatibility

This bundle is designed for efficient heating and cooling in both residential and light commercial applications. The MXZ-4D30NL outdoor condenser is compatible with up to four indoor units, allowing for flexible installation in various room configurations. The MSZ-FX06NL and MSZ-FX18NL air handlers are ideal for single-zone or multi-zone systems, providing customizable comfort and energy efficiency.
