Mitsubishi Multi-Zone 28600 BTU R-454B 20 SEER2 3-Zone Wall-Mounted Mini Split Heat Pump System - 6K+6K+15K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-4D30NL outdoor condenser paired with two advanced wall-mounted air handlers, the MSZ-GX06NL and MSZ-GX15NL. Designed for both residential and light commercial applications, this combination provides efficient heating and cooling across multiple zones. The outdoor unit delivers a robust 30,000 BTU cooling capacity, while the air handlers offer flexible configurations to suit various room sizes. With advanced features such as built-in Wi-Fi, quiet operation, and superior filtration systems, this bundle ensures optimal comfort and convenience throughout the year.

What's Included

• MITSUBISHI ELECTRIC MXZ-4D30NL - Mitsubishi Electric MXZ-4D30NL 30k BTU (2.5 Ton) M-Series Outdoor Condenser (Qty x1)
• MITSUBISHI ELECTRIC MSZ-GX06NL - Mitsubishi Electric MSZ-GX06NL R454B 6k BTU Heat Pump Wall Mount Air Handler (Qty x2)
• MITSUBISHI ELECTRIC MSZ-GX15NL - Mitsubishi Electric MSZ-GX15NL R454B 15k BTU Heat Pump Wall Mount Air Handler (Qty x1)

Key Details

• Weight of Bundle: 197 lb (Mitsubishi 131 lb + Mitsubishi 44 lb + Mitsubishi 22 lb)
• Cooling BTU: 30,000 (MXZ-4D30NL), 6,000 (MSZ-GX06NL), 15,000 (MSZ-GX15NL)
• Heating BTU: 36,000 (MXZ-4D30NL), 7,200 (MSZ-GX06NL), 18,000 (MSZ-GX15NL)
• SEER Rating: 21 (MXZ-4D30NL), Up to 28.4 (MSZ-GX06NL)
• Voltage: 208/230V
• Noise Level: 52 dB(A) (MXZ-4D30NL), As low as 19 dB(A) (MSZ-GX06NL)
• Dimensions: MXZ-4D30NL - 31.43" H x 37.45" W x 13" D; MSZ-GX06NL - 11.77" H x 31.40" W x 9.65" D; MSZ-GX15NL - 11.77" H x 31.40" W x 9.65" D
• Weight: 137 lbs (MXZ-4D30NL), 27 lbs (MSZ-GX06NL), 23 lbs (MSZ-GX15NL)

Use & Compatibility

This bundle is ideal for residential and light commercial heating and cooling needs, supporting both single-zone and multi-zone configurations. The MXZ-4D30NL outdoor condenser works seamlessly with the MSZ-GX06NL and MSZ-GX15NL air handlers, providing a versatile solution for various room sizes and layouts.
