Mitsubishi Multi-Zone 28600 BTU R-454B 20 SEER2 3-Zone Wall-Mounted Hyper Heat Mini Split Heat Pump System - 9K+9K+12K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-4D30NL outdoor condenser and two wall-mounted air handlers, the MSZ-FX09NL and MSZ-FX12NL. Designed for multi-zone applications, this system provides efficient heating and cooling across various spaces. The outdoor unit delivers powerful performance with a 30,000 BTU capacity, while the indoor units offer additional comfort with capacities of 9,000 BTU and 12,000 BTU, respectively. Each component is equipped with advanced filtration and smart technology, ensuring a comfortable and healthy indoor environment year-round.

What's Included

• MITSUBISHI ELECTRIC MXZ-4D30NL - Mitsubishi Electric MXZ-4D30NL 30k BTU (2.5 Ton) M-Series Outdoor Condenser (Qty x1)
• MITSUBISHI ELECTRIC MSZ-FX09NL - Mitsubishi Electric MSZ-FX09NL FX-Series Wall Mounted Unit 9k BTU Hyper Heat Air Handler (Qty x2)
• MITSUBISHI ELECTRIC MSZ-FX12NL - Mitsubishi Electric MSZ-FX12NL FX-Series Wall Mounted Unit 12k BTU Hyper Heat Air Handler (Qty x1)

Key Details

• Weight of Bundle: 240.2 lb (Mitsubishi 131 lb + Mitsubishi 72.8 lb + Mitsubishi 36.4 lb)
• Cooling BTU: 30,000 (MXZ-4D30NL), 9,000 (MSZ-FX09NL), 12,000 (MSZ-FX12NL)
• Heating BTU: 36,000 (MXZ-4D30NL), 12,000 (MSZ-FX09NL), 13,200 (MSZ-FX12NL)
• SEER Rating: 21 (MXZ-4D30NL), Up to 35 (MSZ-FX12NL)
• Voltage: 208/230V
• Sound Levels: 20 dB (min) to 56 dB (max)
• Dimensions: MXZ-4D30NL - 31.43" H x 37.45" W x 13" D; MSZ-FX09NL & MSZ-FX12NL - 12" H x 39.27" W x 9.75" D
• Refrigerant Type: R-454B

Use & Compatibility

This bundle is ideal for both residential and light commercial applications, providing efficient heating and cooling for multiple zones. The outdoor condenser is compatible with the included wall-mounted air handlers, making it a versatile solution for various room sizes and configurations.
