Mitsubishi Multi-Zone 28600 BTU R-454B 20 SEER2 3-Zone Wall-Mounted Hyper Heat Mini Split Heat Pump System - 6K+12K+12K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-4D30NL outdoor condenser and two wall-mounted air handlers (MSZ-FX06NL and MSZ-FX12NL). Designed for both residential and light commercial applications, this system provides efficient heating and cooling across multiple zones. The outdoor unit boasts a powerful 30,000 BTU capacity, while the air handlers offer versatile options for different room sizes, ensuring optimal comfort year-round. With advanced features like variable speed compressors and smart device compatibility, this bundle is perfect for those seeking energy-efficient climate control solutions.

What's Included

• MITSUBISHI ELECTRIC MXZ-4D30NL - Mitsubishi Electric MXZ-4D30NL 30k BTU (2.5 Ton) M-Series Outdoor Condenser (Qty x1)
• MITSUBISHI ELECTRIC MSZ-FX06NL - Mitsubishi Electric MSZ-FX06NL FX-Series Wall Mounted Unit 6k BTU Hyper Heat Air Handler (Qty x1)
• MITSUBISHI ELECTRIC MSZ-FX12NL - Mitsubishi Electric MSZ-FX12NL FX-Series Wall Mounted Unit 12k BTU Hyper Heat Air Handler (Qty x2)

Key Details

• Weight of Bundle: 232.8 lb (Mitsubishi 131 lb + Mitsubishi 29 lb + Mitsubishi 72.8 lb)
• Cooling BTU: 30,000 (MXZ-4D30NL), 6,000 (MSZ-FX06NL), 12,000 (MSZ-FX12NL)
• Heating BTU: 36,000 (MXZ-4D30NL), 9,000 (MSZ-FX06NL), 13,200 (MSZ-FX12NL)
• SEER Rating: 21 (MXZ-4D30NL), Up to 35 (MSZ-FX06NL, MSZ-FX12NL)
• Voltage: 208/230V
• Dimensions: MXZ-4D30NL - 31.43" x 37.45" x 13"; MSZ-FX06NL/MSZ-FX12NL - 12" x 39.27" x 9.75"
• Weight: MXZ-4D30NL - 137 lbs; MSZ-FX06NL - 36.4 lbs; MSZ-FX12NL - 36.4 lbs
• Noise Level: MXZ-4D30NL - 52 dB(A) cooling, 56 dB(A) heating; MSZ-FX06NL - 20-42 dB; MSZ-FX12NL - 20-44 dB

Use & Compatibility

This bundle is ideal for multi-zone heating and cooling applications, suitable for both residential and light commercial use. The outdoor condenser can support up to four zones, while the wall-mounted units are compatible with various room sizes and layouts, providing efficient climate control tailored to your needs.
