Mitsubishi Multi-Zone 28600 BTU R-454B 16 SEER2 3-Zone Ducted Low-Static Mini Split Heat Pump System - 9K+9K+18K

Description

This comprehensive HVAC bundle features the Mitsubishi Electric MXZ-4D30NL outdoor condenser and two indoor concealed duct air handling units (AHUs) - the SEZ-AD09NL and SEZ-AD18NL. Together, these components create a versatile and efficient multi-zone heating and cooling system suitable for both residential and light commercial applications. The outdoor condenser delivers powerful performance with a 30,000 BTU cooling capacity, while the indoor units provide flexible installation options and quiet operation, ensuring comfort across multiple spaces. With advanced features like WiFi control and built-in condensate pumps, this bundle is designed to meet diverse climate control needs.

What's Included

• MITSUBISHI ELECTRIC MXZ-4D30NL - Mitsubishi Electric MXZ-4D30NL 30k BTU (2.5 Ton) M-Series Outdoor Condenser (Qty x1)
• MITSUBISHI ELECTRIC SEZ-AD09NL - Mitsubishi Electric SEZ-AD09NL 9k BTU (0.75 Ton) 208/230V M-Series Concealed Duct AHU (R-454B) (Qty x2)
• MITSUBISHI ELECTRIC SEZ-AD18NL - Mitsubishi Electric SEZ-AD18NL 18k BTU (1.50 Ton) 208/230V M-Series Concealed Duct AHU (R-454B) (Qty x1)

Key Details

• Weight of Bundle: 269 lb (Mitsubishi 131 lb + Mitsubishi 80 lb + Mitsubishi 58 lb)
• Cooling BTU: 30000 (MXZ-4D30NL), 9000 (SEZ-AD09NL), 18000 (SEZ-AD18NL)
• Heating BTU: 36000 (MXZ-4D30NL), 10900 (SEZ-AD09NL), 18000 (SEZ-AD18NL)
• SEER Rating: 21 (MXZ-4D30NL)
• Voltage: 208/230V (All units)
• Sound Level: 52 dB(A) (MXZ-4D30NL), 30 dB (SEZ-AD09NL), 30 dB (SEZ-AD18NL)
• Dimensions: MXZ-4D30NL - 31.43 x 37.45 x 13 in; SEZ-AD09NL - 7.875 x 31.125 x 27.5625 in; SEZ-AD18NL - 7.875 x 46.875 x 27.5625 in
• Weight: 137 lbs (MXZ-4D30NL), 42 lbs (SEZ-AD09NL), 60 lbs (SEZ-AD18NL)

Use & Compatibility

This bundle is intended for use in residential and light commercial settings, providing efficient heating and cooling across multiple zones. The outdoor condenser is compatible with the included indoor units, which can be discreetly installed in various locations, including attics and ceilings, making it ideal for homes and offices that require flexible climate control solutions.
