Mitsubishi Electric Trane Hvac TRUZH0241HA10NA Outdoor Unit 24,000 BTU/H

Product Description

The MITSUBISHI ELECTRIC TRANE HVAC TRUZH0241HA10NA is an outdoor unit with a capacity of 24,000 BTU/H. It features a variable speed inverter compressor and hyper-heating capabilities. It also includes efficiency ratings, electrical specifications, and available accessories. Pre-charged with refrigerant volume for piping length up to 70 ft.

• Variable speed INVERTER-driven compressor
• Wide heating range: heating performance down to -13°F
• Built-in base pan heater

Product Highlights

The TRUZH0241HA10NA outdoor unit is designed for efficient and reliable performance, even in extreme temperatures.

Product Information

Standard Information

• Brand: MITSUBISHI ELECTRIC TRANE HVAC
• Manufacturer Part Number: TRUZH0241HA10NA

Technical Specifications

• Cooling at 95 °F Maximum Capacity BTU/H: 24,000
• Cooling at 95 °F Rated Capacity BTU/H: 24,000
• Cooling at 95 °F Minimum Capacity BTU/H: 10,000
• Cooling at 95 °F Maximum Power Input W: 1,900
• Cooling at 95 °F Rated Power Input W: 1,900
• Cooling at 95 °F Moisture Removal Pints/h: 5.0
• Cooling at 95 °F Sensible Heat Factor: 0.77
• Cooling at 95 °F Power Factor [208V/230V] %: 96.0 / 96.0
• Heating at 47 °F Maximum Capacity BTU/H: 28,000
• Heating at 47 °F Rated Capacity BTU/H: 26,000
• Heating at 47 °F Minimum Capacity BTU/H: 10,000
• Heating at 47 °F Maximum Power Input W: 2,150
• Heating at 47 °F Rated Power Input W: 1,920
• Heating at 47 °F Power Factor [208V/230V] %: 96.0 / 96.0
• Heating at 17 °F Maximum Capacity BTU/H: 26,000
• Heating at 17 °F Rated Capacity BTU/H: 17,200
• Heating at 17 °F Maximum Power Input W: 3,560
• Heating at 17 °F Rated Power Input W: 2,006
• Heating at 5 °F Maximum Capacity BTU/H: 26,000
• Heating at 5 °F Maximum Power Input W: 3,986
• Heating at -13 °F Maximum Capacity BTU/H: 20,800
• Efficiency SEER: 19.5
• Efficiency EER2: 12.6
• Efficiency HSPF2 [IV]: 9.5
• Efficiency COP at 47 °F2: 3.96
• Efficiency COP at 17 °F at Maximum Capacity3: 2.1
• Efficiency COP at 5 °F at Maximum Capacity4: 1.9
• Electrical Voltage, Phase, Frequency: 208/230, 1, 60
• Electrical Guaranteed Voltage Range VAC: 198-253
• Electrical Voltage: Indoor-Outdoor, S1-S2 VAC: 208/230
• Electrical Voltage: Indoor-Outdoor, S2-S3 VDC: 24
• Electrical Short-circuit Current Rating [SCCR] kA: 5
• Electrical Recommended Fuse/Breaker Size (Outdoor) A: 25
• Electrical Recommended Wire Size [Indoor-Outdoor] AWG: 14
• Outdoor Unit MCA A: 17.0
• Outdoor Unit MOCPA: 27
• Outdoor Unit Fan Motor Output W: 74
• Outdoor Unit Airflow Rate [Cooling / Heating] CFM: 1940 / 1940
• Outdoor Unit Refrigerant Control: LEV
• Outdoor Unit Defrost Method: Reverse Cycle
• Outdoor Unit Sound Pressure Level, Cooling1 dB(A): 52
• Outdoor Unit Sound Pressure Level, Heating2 dB(A): 53
• Outdoor Unit Compressor Type: Scroll
• Outdoor Unit Compressor Model: DNB28FBAM
• Outdoor Unit Compressor Rated Load Amps A: 9
• Outdoor Unit Compressor Locked Rotor Amps A: 18.0
• Outdoor Unit Compressor Oil [Type // Charge] oz.: FVC68D // 34
• Outdoor Unit External Finish Color: Ivory
• Outdoor Unit Munsell: 3Y7.8/1.1
• Outdoor Unit Base Pan Heater: Built-in
• Outdoor Unit Operating Temperature Range Cooling Air Temp [Maximum / Minimum]* °F: 115 DB / 0 DB
• Outdoor Unit Operating Temperature Range Heating Air Temp [Maximum / Minimum] °F: 70 DB, 59 WB / -13 DB, -13 WB
• Outdoor Unit Heating Thermal Lock-out/Re-start Temperatures** °F: -22 / -13
• Outdoor Unit Refrigerant Type: R410A
• Outdoor Unit Pre-Charged Refrigerant Amount Lbs, oz: 7.0, 11.0
• Outdoor Unit Maximum Pre-Charged Piping Length Ft. [m]: 70.0 [21.0]
• Outdoor Unit Additional Refrigerant Charge Per Additional Piping Length oz./Ft. [g/m]: 0.7 [65]
• Outdoor Unit Piping Gas Pipe Size O.D. [Flared] In. [mm]: 5/8 [15.88]
• Outdoor Unit Piping Liquid Pipe Size O.D. [Flared] In. [mm]: 3/8 [9.52]
• Outdoor Unit Maximum Piping Length Ft. [m]: 165 [50]
• Outdoor Unit Maximum Height Difference Ft. [m]: 100 [30]
• Outdoor Unit Maximum Number of Bends: 15
