Mitsubishi Electric SVZ-AP48NL idu, air handler, svz-ap, 48000 btu

Product Description

The MITSUBISHI ELECTRIC SVZ-AP48NL is an IDU air handler with a 48,000 BTU/h cooling capacity and uses R454B refrigerant. It operates at 208/230V/1P. The ducted air handler provides a solution to cool and heat large zones. It features a unique blow-through design for simple coil cleaning.

• Features a unique blow-through design for simple coil cleaning
• Selectable external static pressure with 3 fan speeds at each static setting
• Multi-position installation: horizontal (left or right), vertical (up or down)

Product Highlights

This Mitsubishi Electric ducted air handler offers efficient cooling and heating with multiple control options and flexible installation.

Product Information

Standard Information

• Brand: MITSUBISHI ELECTRIC
• Manufacturer Part Number: SVZ-AP48NL

Technical Specifications

• BTU/h: 48,000
• Voltage: 208/230V/1P
• Refrigerant Type: R-454B
• Brand Name: Mitsubishi Electric
• MPN: SVZ-AP48NL
• Cooling Capacity: 48000 Btu/hr
• Heating Capacity: 60000 Btu/hr
• Amperage Rating: 5.63 A
• CFM Rating: 1040 to 1485 cfm
• Compressor Type: Twin Rotary
• Connection Size: 3/4 in
• Connection Type: Flared
• EER Rating: 9.1
• Filter Size: 20 x 24 x 1 in
• Frequency Rating: 60 Hz
• Fuse Rating: 40 A
• Liquid Line Size: 3/8 in
• Motor Type: ECM
• Number of Speeds: 3
• Phase: 1 ph
• Pressure Rating: 0.8 in-WG
• SEER Rating: 17.1
• Sound Level: 52 dBA
• Suction Line Size: 3/4 in
• Voltage Rating: 208/230 V
• Wattage: 4450 W
• Installation Type: Ducted
• Manufacturer Name: Mitsubishi
• Unit Type: Indoor
