Mitsubishi Electric SUZ-KA09NAHZ KA 9,000 BTU 18.9 SEER Hyper Heat Universal Heat Pump Outdoor Unit

Product Description

The Mitsubishi Electric SUZ-KA09NAHZ hyper heat universal heat pump outdoor unit is an efficient heating and cooling option for a small to mid-sized room. This unit can be used with 4-way or 1-way ceiling cassette or horizontal ducted units. The outdoor condenser is equipped with inverter technology and an electronic linear expansion valve.

• Extremely efficient heating and cooling option
• Can be used with 4-way or 1-way ceiling cassette or horizontal ducted units
• Hyper Heat

Product Highlights

Efficient heating and cooling with Hyper Heat technology. Compatible with various indoor units. Inverter technology improves temperature accuracy and system efficiency.

Product Information

Standard Information

• Brand: MITSUBISHI ELECTRIC
• Manufacturer Part Number: SUZ-KA09NAHZ

Technical Specifications

• Unit Type: Universal Outdoor
• Product Line: M-Series KA, Hyper Heat
• Operating Mode: Cooling & Heating
• Low Ambient Heat: Yes
• Number of Zones: 1
• Unit Size: 9,000 BTU
• Line Set Size: 1/4" x 3/8"
• Required Install Kit: IKIT1438
• Outdoor Unit: SUZ-KA09NAHZ
• Cooling Capacity: 9000 BTU
• Heating Capacity: up to 14,000 BTU
• SEER: 17.3 - 20.02
• EER: 12.5 - 15.0
• HSPF: 9.8 - 11.0
• Heating Minimum Temp: -14 F
• Cooling Minimum Temp: 14 F
• Room Cooling/Heating Capacity: up to 350 sq ft
• Product Sub-line: Hyper-Heating
• Product Category: Mini Split System Components
• Multi-Zone Compatible: No
• Refrigerant Type: R-410A
• Installation Location: Outdoor
• Base Pan Heater Included: Yes
• Cooling BTU: 9000
• Heating BTU: 14000
• Maximum Sound Level: 55 dB
• Minimum Outdoor Temperature for Heating: -13 F
• Voltage: 208/230 Volts
• Phase: 1
• Frequency: 60 Hz
• Minimum Circuit Ampacity: 14 Amps
• Recommended Breaker Size: 15 Amps
• Maximum Line Length: 65 Feet
• Gas Connection Size: 3/8 Inch
• Liquid Connection Size: 1/4 Inch
• Product Height: 34 5/8 Inches
• Product Width: 38 9/16 Inches
• Product Depth: 13 Inches
• Product Weight: 129 Pounds
• ETL Listed: Yes
