Mitsubishi Electric MXZ-SM36NL Multi-Zone Heat Pump Condenser

Product Description

The Mitsubishi Electric MXZ-SM36NL is an outdoor heat pump condenser designed for multi-zone mini-split systems. It works with M-, P-Series, and CITY MULTI indoor units. This allows for customized heating and cooling across various zones. The unit features an INVERTER-driven compressor and utilizes R454B refrigerant.

• Connects to multiple indoor units for zoned climate control.
• Compatible with M-, P-Series, and CITY MULTI indoor units.
• Can serve up to 4 zones with a branch box or 11 zones without.

Product Highlights

This heat pump condenser provides efficient heating and cooling for residential and commercial applications. It is suitable for installations where individual room control is required.

Product Information

Standard Information

• Brand: Mitsubishi Electric
• MPN: MXZ-SM36NL

Technical Specifications

• Model Number: MXZ-SM36NL
• Product Line: Smart Multi Series
• Unit Type: 3-Ton Inverter Condenser
• Operating Mode: Cooling & Heating
• Unit Size: 36,000 BTU
• Refrigerant Type: R454B
• Number of Zones: 4 (with branch box) or 11 (without branch box)
• Cooling Capacity at 95F (Btu/h): Maximum 36,000, Minimum 13,000
• Heating Capacity at 47F (Btu/h): Maximum 41,000, Minimum 12,600
• Heating Capacity at 5F (Btu/h): Maximum 29,000
• SEER2: 23
• EER2: 14.10
• HSPF2: 11
• Heating Minimum Temp: -24°F
• Cooling Minimum Temp: 5°F (with wind baffles installed)
• Room Cooling/Heating Capacity: Up to 1500 sq ft
• Dimensions: 41-11/32 W x 13 D x 52-11/16 H
