Mitsubishi Electric MSZ-FX12NL-U1 Hi-Seer Hyper Heat Air Handler 12,000 BTU

Product Description

The Mitsubishi Electric MSZ-FX12NL-U1 is a 12,000 BTU Hi-Seer Hyper Heat Air Handler, R-454B. It provides efficient heating and cooling for spaces up to 500 sq ft. This indoor unit features smart controls, advanced filtration, and pairs with FX outdoor units for year-round comfort.

• Cooling capacity of 12,000 BTU and heating capacity of 13,200 BTU.
• Equipped with a 3D i-see Sensor that scans the room to adjust temperature and airflow based on occupancy.
• Features a Dual Barrier Coating to reduce dust and contaminants on the heat pump's inner surface.

Product Highlights

This wall-mounted unit offers multiple fan speeds, quiet operation, and Wi-Fi enabled control via the Comfort app.

Product Information

Standard Information

• Brand: MITSUBISHI ELECTRIC
• Manufacturer Part Number: MSZ-FX12NL-U1

Technical Specifications

• Application: Cooling Heating
• Cooling Capacity (BTU): 12000
• Heating Capacity (BTU): 13200
• Product Type: Indoor Unit
• Voltage: 208/230V
• Mount: Wall
• Refrigerant Type: R454B
• Number of Zones: 1
• Energy Star Rated: Yes
• Unit Type: Indoor Unit
• Product Line: FX Series
• Operating Mode: Heating and Cooling
• System Capacity: 12,000 BTU
• Line Set Size: 1/4" x 3/8"
• WiFi Enabled: Yes with Comfort App
• WiFi Built In: Yes
• Indoor Unit: MSZ-FX12NL
• Remote Controller: Included
• Airflow Cooling CFM, Dry: 198-247-311-406-526
• Airflow Cooling CFM, Wet: 168-210-264-345-447
• Airflow Heating CFM, Dry: 177-247-311-406-477
• Noise Level dB(A), Cooling: 20-24-29-36-44
• Noise Level dB(A), Heating: 21-24-29-36-42
• Refrigerant: R-454B
• Nominal CFM: 168-526
• Liquid Line: 1/4"
• Suction Line: 3/8"
• Nominal Tons: 1 Ton
