Mitsubishi Electric MSZ-FX09NL-U1 9,000 Btu Hi-Seer Hyper Heat Air Handler, R-454B

Product Description

The Mitsubishi Electric MSZ-FX09NL-U1 is a 9,000 BTU Hi-Seer Hyper Heat Air Handler, R-454B. This wall-mounted indoor unit offers quiet, energy-efficient comfort for rooms. Features include smart control capability and air purification. It pairs with FX outdoor units for reliable, year-round performance and quality.

• Features a 3D i-see Sensor that scans each room to adjust temperature and airflow based on user preference.
• Equipped with Dual Barrier Coating that reduces the collection of contaminants on the inner surface of the heat pump.
• Offers multiple control options including a remote controller, comfort app, and third-party interfaces.

Product Highlights

The MSZ-FX09NL-U1 provides efficient heating and cooling with smart features for optimal comfort and air quality.

Product Information

Standard Information

• Brand: MITSUBISHI ELECTRIC
• Manufacturer Part Number: MSZ-FX09NL-U1

Technical Specifications

• Heating Capacity (BTU): 12000
• Product Type: Indoor Unit
• Number of Zones: 1
• Application: Heating Cooling
• Voltage: 208/230V
• Energy Star Rated: Yes
• Refrigerant Type: R454B
• Mount: Wall
• Cooling Capacity (BTU): 9000
• Unit Type: Wall Mounted
• Product Line: FX Series
• Operating Mode: Heating and Cooling
• System Capacity: 9,000 BTU
• Line Set Size: 1/4" x 3/8"
• WiFi Enabled: Yes with Comfort App
• WiFi Built In: Yes
• Indoor Unit: MSZ-FX09NL
• Remote Controller: Included
• Airflow Cooling CFM, Dry: 198-233-311-406-526
• Airflow Cooling CFM, Wet: 168-198-264-345-447
• Airflow Heating CFM, Dry: 177-247-311-406-477
• Noise Level dB(A), Cooling: 20-23-29-36-44
• Noise Level dB(A), Heating: 20-24-29-36-42
• Nominal CFM: 168-526
• Nominal Tons: 0.75 Ton
• Suction Line: 3/8\
• Liquid Line: 1/4\"
