Mitsubishi Electric MLZ-KX06NL One-Way Ceiling Cassette Unit 6,000 BTU

Product Description

The Mitsubishi MLZ-KX06NL is a 6,000 BTU M-Series 1-Way Ceiling Cassette multi-zone only air handler. This efficient heating and cooling option is designed for rooms up to 200 sq ft and fits between 16" o.c. ceiling joists. This indoor unit must be connected to a 454B multi-zone outdoor unit.

• Adjustable fan speeds and vane directions for customized airflow.
• Built-in condensate lift mechanism (19.6") reduces the need for an additional pump.
• Wi-Fi enabled for control via the Comfort app.

Product Highlights

The MLZ-KX06NL features adjustable fan speeds, a built-in condensate lift, and Wi-Fi connectivity for convenient control.

Product Information

Standard Information

• Brand: MITSUBISHI ELECTRIC
• Manufacturer Part Number: MLZ-KX06NL-U1

Technical Specifications

• Unit Type: Ceiling Cassette 1-Way
• Product Line: M-Series EZ FIT
• Operating Mode: Cooling & Heating
• Number of Zones: 1
• System Capacity: 6,000 BTU
• Line Set Size: 1/4" x 3/8"
• WiFi Enabled: Yes with Comfort App
• WiFi Built In: Yes
• Indoor Unit: MLZ-KX06NL
• Indoor Unit Grille: MLP-448
• Cooling Capacity: 6000 BTU
• Heating Capacity: 7200 BTU
• Room Cooling/Heating Capacity: up to 200 sq ft
• Airflow Cooling CFM, Dry: 152 173 184 198
• Airflow Cooling CFM, Wet: 129 141 156 168
• Airflow Heating CFM, Dry: 152 173 194 212
• Noise Level dB(A), Cooling: 29, 31, 34, 36
• Noise Level dB(A), Heating: 29, 32, 35, 37
• Unit Size W x D x H: 33-3/16 x 11-7/8 x 7-11/16
• BTU: 6,000 BTU/h
• Voltage: 208/230V/1P
• Refrigerant: R454B
• Type: Ceiling Cassette
• Product Category: Mini Split System Components
• Multi-Zone Compatible: Yes
• Remote Control: Wireless
• Indoor Unit Size(s): 6
• Installation Location: Indoor
• Grille: Included
• Required Grille Model: MLP-448WU
• Maximum Air Flow: 212 CFM
• Minimum Air Flow: 152 CFM
• Minimum Sound Level: 29 dB
• Maximum Sound Level: 37 dB
• Phase: 1
• Frequency: 60 Hz
• Gas Connection Size: 3/8 Inch
• Liquid Connection Size: 1/4 Inch
• Product Height: 7 11/16 Inches
• Product Width: 33 3/16 Inches
• Product Depth: 11 7/8 Inches
• Product Weight: 25 Pounds
• ETL Listed: Yes
• Series: M-Series
• Model: MLZ-KX
• Capacity range: 6,000 to 18,000 BTU/H
• Sound level: As low as 27 dB(A)
• ENERGY STAR: Yes
• SEER2: Up to 20.9
• HSPF2: Up to 12.2
