Mitee-bite 33110 Locating Positioning Rail 1/4-20

Product Description

The MITEE-BITE 33110 is a single-hole locating and positioning rail designed for precision workholding applications in machining and fixturing setups. Machined from low carbon steel, this compact rail measures 0.75 inches long, 0.48 inches wide, and 0.35 inches high, making it suitable for tight fixture layouts where space is at a premium. It accepts a 1/4-20 thread fastener for secure clamping. An optional tungsten carbide coating is available to increase holding force when application demands higher friction resistance. This part is typically installed by machinists, toolmakers, and fixturing specialists working with CNC mills, jig plates, and modular workholding systems.

The 33110 positioning rail fits applications where repeatable part location is required on fixture plates, tombstones, or dedicated jigs. Its low-profile geometry allows use in confined areas of a fixture assembly. The single-hole design keeps setup simple while still delivering reliable locating force when properly torqued with a compatible 1/4-20 fastener. Common use cases include production machining environments, job shops, and prototype fixturing where consistent datum location is critical.

Key Features

• Low carbon steel construction provides good machinability and adequate strength for general workholding duty
• Optional tungsten carbide coating available to increase holding and friction force
• 1/4-20 threaded hole for standard fastener compatibility
• Compact footprint: 0.75 inches long, 0.48 inches wide, 0.35 inches high
• Single-hole design simplifies installation in tight fixture layouts

Compatibility

Designed as an OEM-style replacement and standard component for use in modular workholding and precision fixturing systems requiring 1/4-20 threaded locating rails.

Installation Notes

Installation is performed by machinists or toolmakers during fixture assembly or maintenance. Ensure the fixture plate or jig is fully de-energized and stationary before installing or adjusting locating rails. Use a calibrated torque wrench with the appropriate 1/4-20 fastener to achieve consistent clamping without damaging the rail. Follow shop safety procedures and any applicable fixturing standards when integrating this component into a production workholding setup.
