Mitee-bite 10646 T-slot Fixture Clamp Set 12 Pc Brass

Product Description

The MITEE-BITE 10646 is a 12-piece T-slot fixture clamp set designed for workholding applications on milling machines, machining centers, and CNC fixtures. The set uses a 1/2-13 stud thread and fits an 11/16-inch T-slot, with a step block width of 1 inch and a T-slot nut width of 3/8 inch. All major components are brass construction, which resists galling and corrosion during repeated setups. The set includes six MITEE-BITE fixture clamps, four MITEE-BITE T-nuts, and two hex keys, giving a machinist or toolroom technician everything needed to complete a basic fixturing setup without sourcing additional hardware.

This set is suited for production and prototype machining environments where repeatable, low-profile workholding is required. The 11/16-inch T-slot sizing is common on mid-size milling tables and modular fixture plates. The included hex keys allow quick clamp engagement and release directly at the machine. It is typically installed and managed by machinists, toolmakers, or CNC setup technicians working in job shops or manufacturing facilities.

Key Features

• 12-piece set includes 6 fixture clamps, 4 T-nuts, and 2 hex keys for complete fixturing capability
• 1/2-13 stud thread size for compatibility with standard workholding hardware
• Fits 11/16-inch T-slots found on mid-size milling tables and fixture plates
• Brass construction resists galling and corrosion during repeated clamp cycles
• 3/8-inch T-slot nut width and 1-inch step block width for precise, low-profile clamping
• Hex key-driven design allows fast setup and takedown at the machine

Compatibility

Designed for use in T-slot workholding applications requiring an 11/16-inch T-slot and 1/2-13 stud thread. Verify T-slot dimensions on the machine table or fixture plate before installation.

Installation Notes

Installation is performed by machinists or toolroom technicians during machine setup. Ensure the machine spindle is off and the table is stationary before placing or removing clamps. Use the included hex keys to engage the MITEE-BITE clamping mechanism evenly. Do not over-torque the stud threads, and inspect T-nuts for proper seating in the slot before applying clamping force.
