Mitee-bite 10508 Symmetrical Hex Clamp 5/16 in 4-pack

Product Description

The MITEE-BITE 10508 is a symmetrical machinable hex clamp designed for precision workholding applications in machining and fixturing operations. Built from mild steel, this hex clamp uses a 1/2-13 stud thread and delivers up to 4,000 pounds of holding force when torqued to 65 ft/lb. The hex measures 5/16 inch across and stands 0.4531 inches in hex height, with an overall height of 0.135 inches. The machinable stock amount of 0.3 inches allows the clamp face to be machined flush or profiled to suit the workpiece. Each package contains 4 clamps, making it suitable for multi-point fixturing setups on milling machines, machining centers, and modular fixture plates.

The 10508 hex clamp is used in machine shops, tool rooms, and production environments where low-profile, high-force workholding is required. The symmetrical hex design allows the clamp to be oriented in multiple positions within a fixture grid. The machinable body is well suited for setups where standard strap clamps would interfere with toolpaths or where minimal part contact height is needed. Machinists, tool and die makers, and fixturing specialists are the primary installers of this component.

Key Features

• 4,000 pounds of holding force per clamp for secure workholding under heavy cutting loads
• Symmetrical hex design allows flexible orientation in fixture plates and T-slot tables
• Machinable body with 0.3 inches of machinable stock for custom face profiling
• Mild steel hex head and mild steel stud for compatibility with standard fixturing hardware
• Low overall height of 0.135 inches minimizes interference with toolpaths
• Pack of 4 clamps supports multi-point fixture configurations out of the box

Compatibility

Designed for use with standard 1/2-13 stud thread fixturing systems and modular fixture plates that accept symmetrical hex-style clamps.

Installation Notes

Installation is performed by machinists or fixturing specialists using standard hand tools and torque wrenches. The stud should be threaded into a fixture plate or T-slot nut before seating the hex clamp body. Apply the specified 65 ft/lb torque to achieve rated holding force — do not exceed this value, as over-torquing can damage the stud or clamp body. Ensure the machinable face is profiled as needed before final installation in a production fixture.
