Mission Rubber MR02 66 Flex-Seal® Arc Shielded Adjustable Sewer Repair Couplings

Product Description

The MISSION RUBBER MR02 66 Flex-Seal® Arc Shielded Adjustable Sewer Repair Couplings connect 6" Clay pipe to 6" Cast Iron or Plastic pipe. These high-performance sewer repair couplings are for non-pressure, gravity flow applications only and are recommended for underground installations. Easy to install and reuse.

• Increased band tension secures pipe ends, forming a watertight, root-proof seal, impervious to infiltration and exfiltration.
• Thick, stainless steel shield controls load bearing between coupling and pipe surface, opposing shear forces while maintaining pipe alignment.
• Synthetic rubbers permit considerable distortion withstanding tension and compression. More pliable, easier to install in cold weather applications than elastomeric PVC gaskets.

Product Highlights

The Flex-Seal® couplings feature surgical grade 316 stainless steel clamps and a heavy-duty, 301 series stainless steel shield. These couplings are anti-corrosive, adaptable and sustainable.

Product Information

Standard Information

• Brand: MISSION RUBBER
• Manufacturer Part Number: MR02 66
• Country of Origin: Domestic

Technical Specifications

• Clamps: Surgical Grade 316 Stainless Steel, Nut & Bolt (2 or 4)
• Shield: Heavy-Duty, 301 Series Stainless Steel (6/500" thick) with 300 Series Stainless Steel, Worm Drive Clamps (2)
• Gasket: Molded, One-Piece, Elastomeric Sealing Gasket
• Connects: 6" CL to 6" CI, PL
• A-MIN (IN): 7.2
• A-MAX (IN): 7.8
• B-MIN (IN): 6.27
• B-MAX (IN): 6.62
• C-WIDTH (IN): 6
• Series: MR02
• Nominal Size: 6 Inch
• End Style: Clay x Cast Iron/Plastic
• Length: 6 Inch
• Material: Synthetic Rubber
• Material Specification: ASTM C425/C1173
• ASTM: ASTM A-240, ASTM A-240M, ASTM C-1173, ASTM C-1173-06, ASTM C-425, ASTM D-1149, ASTM D-2240, ASTM D-395, ASTM D-412, ASTM D-471, ASTM D-573
• CSA Certified: CSA B602
• Collection: Flex-Seal MR02 ARC Series
• End Connection 1: Clamp
• End Connection 2: Clamp
• End Connections: Clamp
• FM Approved: No
• Fitting Size 1: 6
• Fitting Size 2: 6
• Fitting Sizes: 6 in
• Fitting Type: Coupling, Straight
• Material Type: 301, 316, Elastomer
• NSF Certified: No
• Origin: Domestic
• UPC: 016846142637
