Mission Rubber MR02 66 ARC WD Flex-Seal® Arc Shielded Adjustable Sewer Repair Couplings

Product Description

The MISSION RUBBER MR02 66 ARC WD Flex-Seal® Arc Shielded Adjustable Sewer Repair Couplings connect 6" Clay pipe to 6" Cast Iron or Plastic pipe. These high-performance sewer repair couplings are designed for non-pressure, gravity flow applications and are recommended for underground installations. They are easy to install and reuse.

• Watertight, root-proof seal, impervious to infiltration and exfiltration.
• Stainless steel shield controls load bearing between coupling and pipe surface.
• Synthetic rubber gasket resists ultraviolet rays, ozone, fungus growth, natural soil erosive properties, and normal sewer gases.

Product Highlights

These couplings offer increased band tension, corrosion resistance and independent clamp tightening adapting to different outside pipe diameters. Cradle to Cradle™ certified.

Product Information

Standard Information

• Brand: MISSION RUBBER
• Manufacturer Part Number: MR02 66 ARC WD

Technical Specifications

• Clamps: Surgical Grade 316 Stainless Steel, Nut & Bolt (2 or 4)
• Shield: Heavy-Duty, 301 Series Stainless Steel (6/500" thick) with 300 Series Stainless Steel, Worm Drive Clamps (2)
• Gasket: Molded, One-Piece, Elastomeric Sealing Gasket
• Connects: 6" CL to 6" CI, PL
• A-MIN (IN): 7.2
• A-MAX (IN): 7.8
• B-MIN (IN): 6.27
• B-MAX (IN): 6.62
• C-WIDTH (IN): 6
