Milwaukee Valve 19500 1/4 - Screwed - Carbon Steel - Ball Valve - 150 SWP - 2000 WOG

Product Description

The Milwaukee Valve 19500 is a carbon steel ball valve with a unibody design. It features a screwed end style, suited for multiple piping applications. With a pressure rating of two thousand psi and a temperature range from negative twenty to four hundred fifty degrees Fahrenheit, this valve performs well in a variety of settings.

• Uni-body construction for enhanced durability
• Suitable for a wide range of piping arrangements
• Threaded ends for easy installation

Product Highlights

This valve is ideal for engineers and plumbing professionals seeking reliable shut-off solutions for water and steam applications.

Product Information

Standard Information

• Brand: Milwaukee Valve
• MPN: 19500

Technical Specifications

• Material: Carbon Steel
• Connection Type: FIP x FIP
• Pressure Rating: 2000 psi
• Temperature Rating: -20 to 450 deg F
• Nominal Size: 1/4 in
• Orifice Size: 0.31 in
• Port Type: Double Reduced
• Top to Inlet Center: 1.97 in
• Inlet to Outlet Length: 2.28 in
