Milwaukee F2885M-212 Cast Iron Flanged Gate Valve

Product Description

The Milwaukee F2885M-212 is a 2-1/2 inch cast iron flanged gate valve. It features an IBBM configuration, suitable for applications requiring a pressure rating from 125 PSI SWP to 200 PSI WOG, non-shock. This valve's construction ensures longevity and reliability in various plumbing applications.

• Flanged end connections for secure fittings.
• Robust cast iron body for durability.
• Designed for pressure systems up to 200 PSI WOG.

Product Highlights

The valve includes an outside stem and yoke design, a bolted bonnet, and a solid wedge disc. The integral yoke and bonnet design utilizes gland packing for effective sealing. Operation is via a sturdy cast iron handwheel, ensuring ease of use.

Product Information

Standard Information

• Item Number: F2885M-212
• Brand: Milwaukee Valves

Technical Specifications

• End Connection: Flanged
• Material: Cast Iron
• Pressure Rating: 125 PSI - 200 WOG
• Product Type: IBBM
• Size: 2-1/2 inches
• Stem Type: OS&Y
• Bonnet Type: Bolted
• Seat Material: Bronze
• Disc Material: Solid Wedge
• Actuator Type: Hand Wheel
• Body Material: Cast Iron
• Inlet to Outlet Length: 7-1/2 inches
• Top to Inlet Center: 16.88 inches
• Trim Material: Brass
