Milwaukee 9572 Electric Chain Hoist 2 Ton 15 Ft

Product Description

The MILWAUKEE 9572 is a 2-ton capacity electric chain hoist designed for heavy-duty overhead lifting in industrial and commercial environments. Built around a multi-disc magnetic brake system, it provides positive load holding and accurate load spotting during operations. An overload limiting clutch protects the hoist and load when lifting capacity is approached or exceeded. Adjustable upper and lower limit switches allow precise control of travel range. The unit ships as a single-piece assembly and is sized for use with a standard top hook mounting arrangement. A 24-volt pushbutton pendant station is included, supporting thumb, trigger, or two-handed operation.

The 9572 is suited for manufacturing facilities, warehouses, machine shops, and maintenance bays where a reliable overhead lifting solution is required. With a 15-foot lift height and a duty service classification of H-3 at up to 25 percent on-time per work period, this hoist is built to handle repetitive lift cycles in demanding production environments. Single-phase or three-phase voltage motor options are available across the Milwaukee electric chain hoist product line to match facility power supply requirements.

Key Features

• 2-ton rated load capacity with overload limiting clutch to prevent damaging overloads
• Multi-disc magnetic brake for positive load holding and accurate spotting
• Adjustable upper and lower limit switches for precise travel regulation
• H-3 duty service classification with up to 25 percent on-time per work period
• 24-volt pushbutton pendant station with thumb, trigger, or two-handed operation
• Latch-type rigid top hook for secure overhead mounting

Compatibility

Designed as a direct-use electric chain hoist for standard overhead lifting applications in industrial and commercial facilities requiring 2-ton capacity at a 15-foot lift height.

Installation Notes

Installation should be performed by a qualified rigger or electrician familiar with overhead lifting equipment and local electrical codes. Before installing, verify that the overhead structure is rated to support the hoist weight plus the maximum load and dynamic forces. Disconnect and lock out all electrical power before making wiring connections. Inspect the top hook, chain, and limit switch operation before placing the hoist into service.

Technical Specifications

• Load Capacity: 2 ton
• Lift Height: 15 feet
• Duty Classification: H-3, up to 25 percent on-time per work period
• Pendant Voltage: 24 volts
• Length: 29.5 inches
• Width: 11.2 inches
• Height: 20 inches
• Weight: 126.8 pounds
• UOM: Each

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 9572
