Milwaukee 9566 Electric Chain Hoist 1 Ton 10 Ft

Product Description

The MILWAUKEE 9566 is a 1-ton capacity electric chain hoist designed for industrial and commercial lifting applications. It delivers reliable, controlled load movement at lifting heights up to 10 feet. A built-in multi-disc magnetic brake provides positive load holding and spotting, while an overload limiting clutch protects against damaging overload conditions. The unit weighs 83 pounds and ships as a single hoist assembly. Adjustable upper and lower limit switches allow the operator to regulate load travel precisely. A 24-volt push button pendant station enables thumb, trigger, or two-handed control. Installers in rigging, maintenance, and general industrial trades specify this hoist for repetitive overhead lifting tasks.

The MILWAUKEE 9566 is suited for overhead lifting in manufacturing facilities, warehouses, maintenance bays, and commercial construction settings. It is rated for H-3 duty service classification, supporting on-time usage up to 25 percent of the work period. Single-phase or three-phase voltage motor options are available to match site power requirements. The 24-volt pendant control station keeps low-voltage operation at the operator level for safe, hands-on load management. This hoist is typically installed by licensed riggers or qualified maintenance personnel following applicable ASME and OSHA overhead lifting standards.

Key Features

• Built-in multi-disc magnetic brake for positive load holding and accurate load spotting
• Adjustable upper and lower limit switches to regulate load travel at both ends of lift range
• Overload limiting clutch protects the hoist and load against damaging overloads
• H-3 duty service classification rated for on-time up to 25 percent of the work period
• 24-volt push button pendant station supports thumb, trigger, or two-handed operation
• Available in single-phase or three-phase motor configurations to match facility power supply

Compatibility

Designed as a direct-use electric chain hoist for standard overhead monorail beam and trolley mounting applications in industrial and commercial environments.

Installation Notes

Installation and rigging should be performed by a qualified rigger or licensed professional familiar with ASME B30.16 standards for overhead hoists. De-energize and lock out the power supply before mounting, wiring, or servicing the unit. Verify that the support structure and beam are rated to handle the combined dead load of the hoist and the intended lifted load. Inspect the top hook latch, chain, and limit switch function before placing the hoist into service.

Technical Specifications

• Capacity: 1 ton
• Lift Height: 10 feet
• Control Voltage: 24 volts
• Duty Classification: H-3, on-time up to 25 percent of work period
• Length: 20.5 inches
• Width: 29.5 inches
• Height: 11.5 inches
• Weight: 83 pounds
• UPC: 0045242069200

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 9566
