Milwaukee 548B-112 Valve 1-1/2 in Spring-Loaded Lift Check Valve

Product Description

The MILWAUKEE 548B-112 is a spring-loaded lift check valve with a 1-1/2 inch nominal size and FNPT end style. Constructed with a bronze body, this valve is designed for silent closing and minimizes water hammer. It has an inlet to outlet length of 3.31 inches and a pressure rating of 250 psi WOG.

• Features a bronze spring and Buna disc ring.
• Includes a bronze disc holder and TFE/Buna disc.
• Suitable for installation in horizontal and vertical lines with upward flow.

Product Highlights

This spring-loaded lift check valve is designed for silent closing and to minimize water hammer in various applications.

Product Information

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 548B - 112

Technical Specifications

• Body Material: Bronze
• End Style: FNPT
• Inlet to Outlet Length: 3.31 in
• Nominal Size: 1-1/2 In
• Pressure Rating: 250 psi WOG
• Series: 548B
• Type: Spring-Loaded
• Mfg. Model: 548B - 112
• Brand: Milwaukee Valves
• Manufacturer: Milwaukee Valve
