Milwaukee 49-57-0020 Arbor Assembly No. 3 Morse Taper

Product Description

The MILWAUKEE 49-57-0020 is a quick-change arbor assembly designed for tang drive Steel Hawg annular cutters used in Milwaukee magnetic drill motors. The assembly includes the arbor, an oil hose, and a hand pump, providing a complete setup for lubricated cutting operations. The arbor features a No. 3 Morse taper shank, allowing secure, repeatable mounting in compatible Milwaukee mag drill units. It is intended for professional tradespeople including electricians, ironworkers, pipefitters, and general contractors who rely on magnetic drill rigs for structural steel and pipe work.

This arbor assembly is built for use in sustained, heavy-duty magnetic drilling applications where annular cutters are driven through steel plate, structural members, or pipe. The integrated oil hose and hand pump system delivers cutting fluid directly to the cutting surface, helping maintain cutter temperature and extending cutter life during continuous use. For best results, Milwaukee Hawg Wash cutting fluid is recommended with this assembly.

Key Features

• Quick-change design for fast cutter swaps on tang drive Steel Hawg annular cutters
• No. 3 Morse taper shank for secure fit in compatible Milwaukee magnetic drill motors
• Includes arbor, oil hose, and hand pump as a complete assembly
• Integrated lubrication system keeps cutting surface cool and reduces cutter wear
• Compatible with Milwaukee Hawg Wash cutting fluid for optimized performance

Compatibility

Designed for use with Milwaukee magnetic drill motors 4292-1 and 4297-2 with tang drive Steel Hawg annular cutters.

Installation Notes

Installation should be performed by a qualified tradesperson familiar with magnetic drill operation and Morse taper tooling. Before mounting or removing the arbor assembly, ensure the magnetic drill motor is fully powered off and unplugged. Seat the Morse taper shank fully and verify a secure fit before applying the magnetic base to the workpiece. Connect the oil hose and load the hand pump with appropriate cutting fluid before beginning drilling operations.

Technical Specifications

• Taper Shank: No. 3 Morse Taper
• Drive Type: Tang Drive
• Includes: Arbor, oil hose, hand pump
• Weight: 1.88 pounds
• Length: 6.1 inches
• Width: 13.2 inches
• Height: 4 inches
• UPC: 0045242201051

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 49-57-0020
