Milwaukee 48-36-1008 High Speed Die Head 3/4 in Npt

Product Description

The MILWAUKEE 48-36-1008 is a high speed forged aluminum die head designed for cutting 3/4 inch NPT right-hand threads on pipe. Built from military-grade forged aluminum, this die head delivers maximum durability while reducing weight by up to 50 percent compared to standard die heads. The enlarged slot openings are approximately 25 percent larger than competing designs, improving chip clearance and visibility during the threading process. A smooth face cap provides a stable handhold when engaging the die onto the pipe. Licensed plumbing contractors and pipefitters are the primary installers of this tool.

This die head is suited for commercial and residential plumbing applications where NPT-threaded pipe connections are required. It is designed for use with pipe threading machines on job sites where portability and speed matter. The 48-36-1008 is compatible with the MILWAUKEE M18 FUEL 2874-20 Pipe Threader with One-Key, the Ridgid 700 Power Drive, and the DeWalt DCE700 Threader, making it a versatile replacement or additional die head for shops running multiple threading platforms.

Key Features

• Forged from military-grade aluminum for high durability and reduced weight
• Up to 50 percent lighter than competitive die heads of equivalent size
• Slots are approximately 25 percent larger for improved chip clearance and thread visibility
• Smooth face cap design provides a comfortable handhold during pipe engagement
• Cuts 3/4 inch NPT right-hand threads at high speed
• Backed by Milwaukee Limited Lifetime Warranty

Compatibility

Compatible with the MILWAUKEE M18 FUEL 2874-20 Pipe Threader with One-Key, the Ridgid 700 Power Drive, and the DeWalt DCE700 Threader.

Installation Notes

Installation and die head changes should be performed by a licensed plumber or pipefitter following the threading machine manufacturer's guidelines. Always power down and disconnect the threading machine before swapping die heads. Ensure the pipe is properly secured in the chuck and that the correct cutting oil is applied before threading to prolong die life and produce clean thread profiles.

Technical Specifications

• Nominal Size: 3/4 inches
• Thread Type: NPT
• Thread Direction: Right
• Die Type: High Speed
• Die Material: Forged Aluminum
• Series: 48-36

Standard Information

• Brand: MILWAUKEE
• Manufacturer Part Number: 48-36-1008
