Milwaukee 48-20-5402 Solid Carbide SDS-Max Core Drill Bit Power 1-1/2 in x 22 in Replacement MPN

Product Description

Milwaukee’s 48-20-5402 solid carbide SDS-Max core drill bit is designed for drilling large holes where depth is relatively shallow. This core bit operates by cutting a kerf, leaving an inside core that must be removed by the operator before deeper drilling is possible. A centering bit, Milwaukee part 48-20-5495, is recommended for optimal results, though it is sold separately. The bit is suitable for use with either SDS-Max or spline shanks and is available in various diameters, ranging from one and a half inches to six inches, with an overall length of twenty-two inches and a drilling depth of three inches.

• Ideal for large hole drilling with one piece carbide design.
• Recommended use with centering bit for accuracy.
• Durable thick-wall construction for demanding applications.

Product Highlights

This tool maximizes energy transfer and efficiency during operation, utilizing an asymmetric tooth pitch that enhances material pulverization. The thick-wall core body provides durability, even under the strain of large hammers. Additionally, the fluted core design minimizes friction loss and promotes faster debris removal.

Product Information

Standard Information

• Brand: Milwaukee Tool
• MPN: 48-20-5402

Technical Specifications

• Diameter: 1-1/2 inches
• Overall Length: 22 inches
• Cutting Depth: 3 inches
• Material: Solid carbide
• Weight: 3.0 LB
• UPC: 045242315499
• GTIN: 00045242315499
• Shank Type: SDS-Max
