Mill-rose 76001 Stop Drain Ball Curb Valve 1 in Fnpt

Product Description

The MILL-ROSE 76001 is a 1-inch stop and drain ball curb valve with female NPT inlet and outlet connections. Built from lead-free brass, it is designed for underground service applications where a single quarter-turn shutoff and integral drain function are required. The 90-degree ball operating head allows full open and full closed positioning with minimal effort. This valve is typically installed by licensed plumbers on residential and light commercial water service lines at the curb stop location.

This valve is suited for potable water service line applications where lead-free materials are required by code. The FNPTxFNPT configuration accepts standard threaded pipe on both ends, making it a straightforward fit in new construction and replacement service scenarios. The integrated stop-and-drain function allows the service line to be drained after shutoff, which is essential in freeze-prone installations.

Key Features

• Lead-free brass construction meets current potable water material standards
• 1-inch FNPTxFNPT connections on both inlet and outlet
• Ball-type operating head with 90-degree rotation for full open or full close
• Integrated stop-and-drain function allows line draining after shutoff
• No lockwing — standard curb key operation
• No tracer wire attachment required

Compatibility

Designed as an OEM-style replacement or new-installation curb stop for 1-inch threaded potable water service line applications requiring lead-free brass stop-and-drain ball valves.

Installation Notes

Installation should be performed by a licensed plumber in accordance with local plumbing codes and IPC requirements. Shut off the main water supply and relieve line pressure before replacing or servicing this valve. Use a curb key matched to the operating head profile for operation after burial. Do not over-torque threaded connections — apply thread sealant or PTFE tape appropriate for potable water service.

Technical Specifications

• Part Type: Stop and Drain
• Series: 76001
• Valve Size: 1 inch
• Inlet Connection: FNPT
• Outlet Connection: FNPT
• Inlet Connection Size: 1 inch
• Outlet Connection Size: 1 inch
• Ball Plug: Ball
• Operating Head Rotation: 90 degrees
• Material: Lead-Free Brass
• Lockwing: No
• Tracer Wire: No
• Product Class: 443

Standard Information

• Brand: MILL-ROSE
• Manufacturer Part Number: 76001
