MILJOCO P2008L-07 Pressure Gauge Utility Service 0-200 PSI & Bar Range

Product Description

The MILJOCO P2008L-07 is a pressure gauge designed for utility service applications. It operates within a range of 0 to 200 PSI and Bar. This gauge features a durable brass construction suitable for air, water, and gas services. A coil siphon must be installed when used for steam applications.

• Pressure range: 0-200 PSI & Bar
• Connection size: 1/4 NPT Bottom
• Accuracy: 3-2-3% ANSI B40.1, Grade B

Product Highlights

This pressure gauge is ideal for general use in light-duty applications and is built to withstand industrial environments.

Product Information

Standard Information

• Manufacturer: MILJOCO
• Part Number: 5757

Technical Specifications

• Size: 2 inches
• Connection Size: 1/4 NPT Bottom
• Accuracy: 3-2-3% ANSI B40.1, Grade B
• Dimension A: 2.08 inches
• Dimension B: 1.04 inches
• Dimension C: 0.55 inches
• Dimension S: 0.74 inches
