Milbank UAP1980-XL-KK-BLG-AEP 200A 4T

Product Description

The Milbank UAP1980-XL-KK-BLG-AEP is a ringless meter socket designed for use in various electrical applications. This product is built to accommodate a continuous amperage rating of two hundred amps and operates at a voltage rating of six hundred VAC. It features a surface mount design, making it suitable for multiple installation setups.

• 200 continuous amperes rating
• Surface mount for easy installation
• UL listed and compliant with Type 3R standards

Product Highlights

The Milbank UAP1980-XL-KK-BLG-AEP is suitable for overhead and underground cable entries. It includes a horn bypass and provides a strong aluminum enclosure, ensuring durability and reliability.

Product Information

Standard Information

• Manufacturer: Milbank
• Application: Meter Socket

Technical Specifications

• Type: Ringless Meter Socket
• Phase: One
• Weight: 8.75 lbs
• Dimensions: Four point five inches by thirteen inches by fifteen point twenty-five inches
• Enclosure Material: Aluminum with Powder Coat Finish
• Insulation Material: Glass Polyester
• Cable Entry: Overhead, Underground, Side Wireway
• Cutout Size: No Main Breaker
