Milbank U8033-XL-KK-BLG 1-Phase Ringless Meter Socket With Horn Bypass 4 Jaw 3-Position 100-Amp

Product Description

The Milbank U8033-XL-KK-BLG is a 1-phase ringless meter socket designed for reliable power distribution. This unit supports a current rating of 100-Amps and operates at a voltage of 300-Volt AC. The meter socket features a surface mountable G90 galvanized steel enclosure with a protective powder coating.

• Rated for 100-Amps and 300-Volt AC
• Features overhead and underground cable entry
• UL listed for safety

Product Highlights

This unit includes a barrel lock with guard provision and four terminal jaws. It has various cable entry options and accommodates wire sizes from 6-AWG to 350-KCMIL on the line side and 6 to 2/0-AWG on the load side.

Product Information

Standard Information

• Brand: Milbank
• Country of Origin: United States of America

Technical Specifications

• Current Rating: 100 Amps
• Voltage Rating: 300 Volt AC
• Dimensions: 16 inches height x 36-11/16 inches width x 4-1/2 inches depth
• Wire Size: 6 AWG - 350 KCMIL (line side), 6 - 2/0 AWG (load side)
• Enclosure Type: NEMA 3R
• Knockouts: 1 x 2 inches, 2 x 2 inches, 3 x 3 inches, 4 x 2 inches, 5 x 1/2 inches, 6 x 1/4 inches, 6 x 1/2 inches, 7 x 5/16 inches concentric
• Standards: UL Listed
• Material: G90 galvanized steel
