Milbank U7021-RL-TG-KK-BLG 200 Amp 4 Term Ringless Small Hub Opening Triplex Ground Horn Bypass

Product Description

The Milbank U7021-RL-TG-KK-BLG is a 200 amp ringless meter socket. It features a small hub opening and a triplex ground horn bypass. This meter socket is built for surface mounting and includes a bracket provision for the barrel lock ground.

• Amperage rating of 200 amps
• UL listed for safety
• Constructed of G90 galvanized steel with a powder-coated finish

Product Highlights

This meter socket is ideal for overhead and underground cable entry applications. It supports wire sizes from 6 AWG to 350 KCMIL. The design includes four terminal jaws for efficient connectivity.

Product Information

Standard Information

• Brand: Milbank
• Country of Origin: United States

Technical Specifications

• Catalog Number: U7021-RL-TG-KK-BLG
• Amperage Rating: 200 Amps
• Voltage Rating: 600 Volts AC
• Frequency Rating: 60 Hertz
• Dimensions: 4.125 Length x 8 Width x 15.5 Height inches
• Material: G90 Galvanized Steel
• Enclosure Type: NEMA 3R
• Knockouts: Various concentric sizes
