Milbank U5168-XTL-200-KK-ALT Single Position Meter Socket with Main and Load Center 200 Amp 1 Phase Ringless Horn 4 Term OH UG 240V

Product Description

The Milbank U5168-XTL-200-KK-ALT is a single position meter socket designed for utility connections and load distribution. This model features a main breaker rated at two hundred amps and is suitable for both overhead and underground installations. The ringless design allows for easier access and maintenance.

• Four terminals for efficient connection.
• Compatible with 240 volts alternating current.
• Constructed from durable G90 galvanized steel.

Product Highlights

This meter socket is designed for use in various applications, ensuring reliable performance for residential and commercial setups. It supports a main breaker with a bypass type, offering flexibility in utility management.

Product Information

Standard Information

• Brand: Milbank
• MPN: U5168-XTL-200-KK-ALT

Technical Specifications

• Amperage Rating: 200
• Application: Meter Socket with Main and Load Center
• Bypass Type: Horn
• Cable Entry: Overhead or Underground
• Enclosure: G90 Galvanized Steel with Powder Coat Finish
• Frequency Rating: 60 Hertz
• Insulation: Glass Polyester
• Material: G90 Galvanized Steel
• Mounting: Surface Mount
• Number of Jaws: 4 Terminal
• Phase: 1
• Standard: UL Listed; Type 3R
• Voltage Rating: Up to 240 Volts AC
