Milbank QN2200RH QN Small Frame Circuit Breaker, Plug-In, 240 VAC, 200 Amp, 22k AIC, 2 Pole

Product Description

The Milbank QN2200RH is a plug-in thermal magnetic circuit breaker designed for use in power distribution systems. This product operates at a voltage of two hundred forty volts AC and supports an amperage rating of two hundred amps. It features a twenty-two kA interrupt rating and is suitable for two-pole configurations, making it ideal for various electrical applications.

• Plug-in connection for easy installation
• Thermal/Magnetic trip for reliable protection
• Compact dimensions at seven point eight inches long, two point five inches wide, and four point one inches high

Product Highlights

The Milbank QN2200RH thermal magnetic circuit breaker is essential for protecting electrical circuits from overloads and short circuits. Its robust design ensures long-lasting performance and reliability in critical applications.

Product Information

Standard Information

• Brand: Milbank
• Manufacturer Part No: QN2200RH

Technical Specifications

• Frame: Small/QNRH
• Phase: 1
• Series: QN Series
• Material: Non-Metallic
• Trip Type: Thermal/Magnetic
• Dimensions: 7.8 in L x 2.5 in W x 4.1 in H
• Voltage Rating: 240 VAC
• Amperage Rating: 200 A
• Connection Type: Plug-In
• Number of Poles: 2
• Frequency Rating: 60 Hz
• Interrupt Rating: 22 kA
• Temperature Rating: 40 deg C
• Actuator Type: Lever Operated
