Milbank Q2100 100A 2-Pole Circuit Breaker

Product Description

The Milbank Q2100 is a two-pole circuit breaker rated for one hundred amps. This breaker works with systems operating on one hundred twenty or two hundred forty volts AC at sixty hertz. It uses a thermal-magnetic mechanism for overcurrent protection and has a ten kAIC interrupting rating.

• Rated for 100 Amps
• Designed for 120/240 VAC systems
• Features thermal-magnetic trip mechanism

Product Highlights

The Milbank Q2100 circuit breaker is reliable for single-phase applications. Ideal for residential and light commercial use, it ensures safety and compliance with electrical standards.

Product Information

Standard Information

• Brand: Milbank
• MPN: Q2100

Technical Specifications

• Circuit Breaker Type: Miniature Breaker
• Amperage: 100 A
• Voltage: 120/240 VAC
• Poles: 2 Pole
• Number of Phases: 1 Phase
• Interrupting Rating: 10 kAIC
• Trip Type: Thermal Magnetic
• Mounting Type: Plug-in
• Line Terminal: Bus
• Load Terminal: Lug
• Wire Size: (1) 8 - 2/0 AWG
• Indicator Type: Common
• Number of Spaces: 2 Space
• Dimensions: 2.56 x 1.98 x 3.19 inches
