Miami Tech FCL05 5 Inch Tab Collar for Fiberglass Duct

Product Description

Miami Tech's FCL05 is a 5 inch tab collar engineered for securing fiberglass duct systems. Ideal for R-4 and R-6 ductboard applications, this product ensures a 180-degree hemmed circumference that eliminates sharp edges, enhancing safety and durability. Miami Tech's innovative design exceeds the Florida building code's (.625 inch) with a flange dimension of .700 inch.

• Designed for both R-4 and R-6 ductboard, with a variant for R-8 ductboard.
• Features a hemmed circumference for increased safety and endurance.
• Exceeds FL Building Code #603.5.6 requirements, affirming its high standard.

Product Highlights

The FCL05 model incorporates several designs for diverse applications including one-piece wide tab collars with and without dampers or scoops, and options with a gasket for enhanced sealing.

Product Information

Standard Information

• Brand: Miami Tech
• MPN: FCL05
• Gauge: 26 GA; 28 GA
• Galvanized: Yes

Technical Specifications

• Width: 5 inches
• Height: 5 inches
• Length: 5.5 inches
• Weight: 0.41 lbs
• Duct Diameter: 5 inches
• Composition: Steel
