Metal-Fab 6M5 Twist-Lock Double Wall Round Gas Vent Pipe 6 Inch x 5 Feet

Product Description

The Metal-Fab 6M5 is a double wall round gas vent pipe designed for gas appliances, including boilers and fireplaces. Measuring six inches in diameter and five feet in length, this Type B gas vent features a twist-lock end design for secure connections. It uses a material thickness of zero point twelve inches for the inner wall made of aluminum alloy and zero point eighteen inches for the outer wall crafted from G90 galvanized steel.

• Double wall construction for improved safety
• Twist-lock design for easy assembly
• Temperature rated up to five hundred thirty degrees Fahrenheit

Product Highlights

Ideal for residential and commercial applications, ensuring compliance with standards such as UL 441 and NFPA 54. Suitable for use with category I gas appliances.

Product Information

Standard Information

• Brand: Metal-Fab
• MPN: 6M5

Technical Specifications

• Diameter: 6 inches
• Length: 5 feet
• End Type: Twist-Lock
• Material Thickness: 0.012 inch (inner wall), 0.018 inch (outer wall)
• Material: Aluminum alloy (flue), G90 galvanized steel (casing)
• Temperature Rating: 530 degrees Fahrenheit
• Applicable Standards: UL 441, NFPA 54/211
• Clearance Requirement: 1 inch
• Applications: Gas boiler, fireplace, furnace, unit heater, radiant tube heater
