Metal-Fab 5M4 5 x 4' Twist-Lock Double Wall Type B Gas Vent Pipe

Product Description

Metal-Fab 5M4 is a type B gas vent pipe with dimensions five inches by four feet. This double wall vent pipe is designed for use with natural gas and propane appliances such as furnaces, boilers, and fireplaces. The inner wall is made of aluminum alloy with a thickness of 0.012 inches while the outer wall consists of G90 galvanized steel with a thickness of 0.018 inches. The vent pipe features a twist-lock end type for easy installation and maintenance.

• Double wall construction for enhanced insulation
• Temperature rating of 530 degrees Fahrenheit
• Meets standards UL 441 and NFPA 54/211

Product Highlights

This gas vent pipe is suitable for various heating applications. Its design facilitates efficient joint alignment during installation, reducing the risk of leaks and ensuring reliability. It is tested and listed for use with approved gas appliances.

Product Information

Standard Information

• Brand: Metal-Fab
• MPN: 5M4

Technical Specifications

• Type: Double Wall, Round, Type B Gas Vent
• Size: 5 inches
• Length: 4 feet
• Material: Aluminum Alloy (Inner Wall), G90 Galvanized Steel (Outer Wall)
• Material Thickness: 0.012 inches (Inner), 0.018 inches (Outer)
• Temperature Rating: 530 degrees Fahrenheit
• End Type: Twist-Lock
• Applicable Standards: UL 441, NFPA 54/211
• Clearance: 1 inch
