Metal-Fab 5M12 Double Wall Round Gas Vent Pipe 5 inch x 12 inch

Product Description

The Metal-Fab 5M12 is a double wall round gas vent pipe designed for efficient venting in HVAC systems. This pipe features a twist-lock end for secure connections, enhancing installation speed and precision. The inner wall uses aluminum alloy with a thickness of 0.012 inches, while the outer casing is made of G90 galvanized steel with a thickness of 0.018 inches.

• Double wall construction ensures safety and durability.
• Type B gas vent compliant with UL 441 and NFPA 54/211 standards.
• Temperature rating of up to 530 degrees Fahrenheit.

Product Highlights

This vent pipe is suitable for gas boilers, fireplaces, furnaces, unit heaters, and radiant tube heaters, making it versatile for various applications. The vent is designed for approved category I appliances burning natural or LP gas.

Product Information

Standard Information

• Brand: Metal-Fab
• MPN: 5M12

Technical Specifications

• Diameter: 5 inches
• Length: 12 inches
• End Type: Twist-Lock
• Material: Aluminum Alloy (Flue), G90 Galvanized Steel (Casing)
• Material Thickness: 0.012 inches (Inner Wall), 0.018 inches (Outer Wall)
• Temperature Rating: 530 degrees Fahrenheit
• Applicable Standard: UL 441, NFPA 54/211
• Clearance: 1 inch
