Mersen W219232 Fuse, 4A, 10mm x 38mm

Product Description

The Mersen W219232 is a 4A fuse with dimensions of 10mm x 38mm. This cylindrical fuse-link offers protection in electrical distribution circuits and various industrial applications. It has ceramic body and silver-plated contacts. Cylindrical fuse-links "aM" are partial range fuses that protect electrical devices against high short-circuit currents with current limiting and low thermal let-through values.

• Fuse Size: 10mm x 38mm
• Voltage Rating: 500VAC
• Amperage: 4A

Product Highlights

The Mersen W219232 fuse provides reliable protection for electrical circuits with a compact design and robust construction.

Product Information

Standard Information

• Brand: Mersen
• Manufacturer Part Number: W219232
• Country of Origin: France

Technical Specifications

• Amps [Specifications]: 4A
• Item [Specifications]: Fuse
• Length [Specifications]: 1.5"
• Diameter [Specifications]: 0.41"
• Mounting [Specifications]: Clip
• Fuse Amps [Specifications]: 4A
• Fuse Size: 10mm x 38mm
• Body Style [Specifications]: Cylindrical
• Ampere Rating: 4 A
• Body Material: Ceramic
• Product Diameter: 10.3 mm
• Fuse Voltage Rating [Specifications]: 500VAC
• Rated Voltage Ac Iec: 500 V
• Speed/Characteristic: aM
• Body Insulating Material: Ceramic
• Connection Terminal Type: Ferrule
• Connection Terminal Material: Silver-Plated Copper
• Ac Max I.R./Breaking Capacity: I1: 120 kA
• Power Dissipation at Rated Current Value: 0.28 W
• AC or DC: AC
• Product Length: 38 mm
• Brand: Mersen
• Current Rating: 4 A
• Manufacturer Part Number: W219232
