Mersen TRS15R TR-R Time-Delay Fuse Class RK5 15 Amps 600 V

Product Description

The Mersen TRS15R is a time-delay fuse designed for overcurrent protection. This Class RK5 fuse features a current-limiting capability to protect motors, transformers, and service entrance equipment. It is rated at fifteen amps and 600 volts, making it suitable for various applications, including feeders and branch circuits. Additionally, it can handle harmless starting currents efficiently.

• Class RK5 designation for superior performance
• Time-delay function for handling inrush currents
• Current-limiting feature reduces peak let-through current

Product Highlights

This fuse is essential for efficient operation in motor control circuits and protects sensitive equipment from overcurrent issues.

Product Information

Standard Information

• Manufacturer: Mersen
• MPN: TRS15R

Technical Specifications

• Type: FUSES
• Voltage Rating: 600 V AC, 300 V DC
• Amperage Rating: 15 A
• Interrupt Rating: 200 kA
• Fuse Type: Time Delay
• Body Size: 13/16 inches diameter by 5 inches length
• Mounting: Clip
• Connection: Ferrule
