Mersen OTM3 Midget Fuse Fast Acting 3 Amp

Product Description

The Mersen OTM3 is a fast-acting midget fuse with a rating of three amps and a voltage of 250 volts AC. This fuse offers reliable protection for circuits requiring quick blow characteristics, making it ideal for various applications involving lighting and heating control. Designed to safeguard against overcurrent, the OTM3 is suitable for use in general electrical systems where time-delay is not needed.

• Fast-acting, designed for quick response to overloads
• Rated for circuits up to 250 volts AC
• Provides supplemental protection for control circuits and lighting

Product Highlights

The OTM3 fuse is engineered for low-cost circuit protection without compromising performance. Its compatibility with UltraSafe fuse holders allows for easy installation and replacement.

Product Information

Standard Information

• Manufacturer: Mersen
• Catalog Number: OTM3

Technical Specifications

• Voltage Rating: 250 VAC
• Amperage Rating: 3 A
• Interrupt Rating: 10 kA
• Mounting Type: Ferrule
• Body Size: 1.5 in x 0.41 in
• Standard Approvals: UL standard 248-14, C22.2 No. 248.14
• Application: Protection for circuits requiring up to 250 VAC and 10 kA
